826925-7
Manufacturer:
TE Connectivity
Mfr.Part #:
826925-7
Datasheet:
Description:
Headers and Wire Housings Through Hole Header, Breakaway Number of Positions:14 Pitch:2.54 mm
| Parameter | Value |
|---|---|
| Termination | Solder |
| Max Operating Temperature | 105 °C |
| Min Operating Temperature | -65 °C |
| Packaging | Bulk |
| Radiation Hardening | No |
| RoHS | Compliant |
| Lead Pitch | 2.54 mm |
| Insulation Resistance | 5 GΩ |
| REACH SVHC | No SVHC |
| Contact Plating | Tin |
| Lead Length | 3.19786 mm |
| Pitch | 2.54 mm |
| Current Rating | 3 A |
| Flammability Rating | UL94 V-0 |
| Orientation | Vertical |
| Lifecycle Status | Production (Last Updated: 1 week ago) |
| Color | Green |
| Gender | Pin (Male) |
| Number of Contacts | 14 |
| ELV | Compliant |
| Number of Poles | 14 |
| Connector Type | Header, Breakaway |
| Number of Positions | 14 |
| Number of Rows | 2 |
| Row Spacing | 2.54 mm |
| Housing Material | PBT |
| Contact Style | Pin |
| Contact Current Rating | 5 A |
| Housing Color | Green |
| Contact Mating Length | 6.7056 mm |
| Keyed | No |
| PCB Mounting Orientation | Vertical |
| Plating Thickness | 2 µm |
| Contact Gender | Male |
| High Temperature Housing | No |
| Mating Post Length | 6.7 mm |
| Contact Shape | Square |
| High Speed Serial Data Connector | No |
| Termination Post Length | 3.2 mm |
Stock: 1275
Distributors
pcbx
pcbxUnit Price$0.82586
Ext.Price$0.82586
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $0.82586 | $0.82586 |
| 10 | $0.70703 | $7.07030 |
| 25 | $0.66881 | $16.72025 |
| 50 | $0.63265 | $31.63250 |
| 100 | $0.59845 | $59.84500 |
| 300 | $0.56502 | $169.50600 |
| 500 | $0.53347 | $266.73500 |
| 1000 | $0.50783 | $507.83000 |
